| Nominal voltage | 220|240 V |
|---|---|
| Voltage type | AC |
| Max. system power | 53 W |
| Max. number of luminaires per miniature circuit breaker B16 (MCB) | 15 |
| Max. number of luminaires per miniature circuit breaker C16 (MCB) | 25 |
| Power factor | 0.95 |
| Surge protection | 1 kV |
| With sensor | No |
| Displacement factor (DF) | ≥ 0.95 |
| Including emergency lighting | No |
| Frequency | 50|60 Hz |
| Colour temperature | 1800|12000 K |
|---|---|
| Rated luminous flux according to IEC 62722-2-1 | 3200 lm |
| Luminaire efficacy | 60 lm/W |
| Colour consistency (SDCM) | 3 |
| Colour rendering index (CRI) | > 95 |
| R9 | 50 |
| Beam angle | 60° |
|---|---|
| Beam angle | 60° up (50%) / 60° down (50%) |
| UGR | 22 |
| Lifetime (L70) | 80000 h |
|---|---|
| Lifetime (L80) | 50000 h |
| On-/Off-cycles | 100000 |
| Dimmability | BLE2 |
|---|---|
| With sensor | No |
| Sensor technology | Microwave (MW) |
| Sensor type | No sensor |
| Protection class | I |
|---|---|
| Degree of protection (IP) | IP40 |
| Impact strength | IK03 |
| Glow wire test | 650°C |
| Risk group (EN 62471) | RG0 |
| Type of control gear | LED operating device current-controlled |
|---|---|
| With control gear | Yes |
| Driver failure rate (at 5,000 hrs) | 0.05% |
| Max. input cable diameter (mm) | 0.75|1.5 mm |
| Wirethrough | No |
| Housing colour | Black |
|---|---|
| Lens material | Polycarbonate |
| Finishing | Black RAL 9004 |
| Coastal proof | No |
| Length | 400 mm |
|---|---|
| Width | 400 mm |
| Height/depth | 1500 mm |
| Outer diameter | 400 mm |
| Application temperature | 25°C |
|---|---|
| Storage environment | -25|50°C |
| Operating temperature | -10|45°C |
| EAN code | EU HS Code | Packaging | Amount | Size (L x W x H) | Weight |
|---|---|---|---|---|---|
| 6941491792590 | 94051190 | CT | 1 | 0.494 x 0.462 x 0.165 m | 7 KG |
