LEDPanelS-P6 Sq595-34W-940-U19
- High quality LED Slim Panel, suitable for offices (UGR19)
- Standard IP54 (front side)
- Recessed, suspended and surface mounting possible
Voltage type | AC/DC |
---|---|
Nominal voltage | 220|240 V |
Max. number of luminaires per miniature circuit breaker B16 (MCB) | 12 |
Max. system power | 34 W |
Max. number of luminaires per miniature circuit breaker C16 (MCB) | 30 |
Power factor | 0.9 |
Max. inrush current | 40.00 A |
Inrush time | 200.0 |
Displacement factor (DF) | ≥ 0.9 |
Max. number of luminaires per miniature circuit breaker C10 (MCB) | 7 |
Max. number of luminaires per miniature circuit breaker C13 (MCB) | 9 |
Nominal voltage DC | 180|280 V |
Frequency | 50|60 Hz |
Equivalent to | TL 4x18W |
---|---|
Colour consistency (SDCM) | 3 |
Colour rendering index (CRI) | > 90 |
Colour temperature | 4000 K |
Luminaire efficacy | 120 lm/W |
Rated luminous flux according to IEC 62722-2-1 | 4080 lm |
CIE Flux Code | 61 88 97 100 100 |
UGR | 19 |
---|---|
Beam angle | 90° |
Beam angle | 90° |
Lifetime (L70) | 100000 h |
---|---|
Lifetime (L80) | 70000 h |
On-/Off-cycles | 100000 |
Lifetime (L90) | 50000 h |
Dimmability | On-Off |
---|
Degree of protection (IP) | IP54 |
---|---|
Protection class | II |
Impact strength | IK03 |
IP recessed part | IP20 |
Glow wire test | 650°C |
Risk group (EN 62471) | RG0 |
With control gear | Yes |
---|---|
Type of control gear | LED operating device current-controlled |
Driver failure rate (at 5,000 hrs) | 1% |
230V Cable length | 1.0 m |
Wirethrough | No |
Housing colour | White |
---|---|
Finishing | White RAL9003 |
Optical material | PMMA |
Cover material | Polycarbonate |
Length | 595 mm |
---|---|
Width | 595 mm |
Height/depth | 25 mm |
Storage environment | -20|50°C |
---|---|
Application temperature | 25°C |
Operating temperature | -10|45°C |
EAN code | EU HS Code | Packaging | Amount | Size (L x W x H) | Weight |
---|---|---|---|---|---|
06941497774774 | 94051190 | CT | 1 | 0.631 x 0.673 x 0.04 m | 2.48 KG |
Accessory Panels - Surface module 600mm x 600mm - White
Accessory Safety cable ceiling kit - 500mm - Stainless steel
Accessory Slim Panel Basic G2 - Mounting springs
Accessory Panels - Frame 644mm x 644mm - White
Accessory Panels - Surface kit 610mm x 610mm - White
Accessory Indoor - Junction box - White
Accessory Slim Panel Perf. UGR19 G6 - Suspension kit
Accessory Panels - Mounting springs 595mm x 595mm
