T8 Tube Performer G2

LEDTubeT8-EMB-P2 L600-6W-840

Product Code
802003020400
  • Single-ended full IEC compliant LED Tube with patented driver
  • Improved efficacy of 170 lm/W
  • Retrofit existing T8 lamps with EM ballast installations ONLY!
  • No warm-up time, 100% light instantly when switched on
  • Full glass body

Specifications

Electrical data

Lamp power 6 W
Nominal voltage 220|240 V
Voltage type AC
Power factor 0.9
Max. inrush current 1.13 A
Inrush time 18.1
Frequency 50|60 Hz

Photometrical data

Colour temperature 4000 K
Lamp efficacy 170 lm/W
Equivalent to TL 1x18W
Colour rendering index (CRI) > 80

Light technical data

Beam angle 220°

Lifespan

Lifetime (L70) 50000 h
On-/Off-cycles 100000

Capabilities

Dimmability On-Off

Certificates and standards

Degree of protection (IP) IP20
Input current 0.029 A
Colour White
Housing colour White
Diameter 26 mm
Length 604 mm
Application temperature 25°C
Storage environment -25|50°C
Operating temperature -20|45°C
EAN codeEU HS CodePackagingAmountSize (L x W x H)Weight
693178304684585395200CT10.645 x 0.026 x 0.026 m0.192 KG
